How To Maintain A Laser Cutting machine

1. Regular inspection and replacement of the nozzle of the laser cutting machine.
2. The chip removal drag chain of the laser cutting machine should be cleaned frequently.
3. Clean up the waste material of the discharge trolley in time.
4. Regularly clean the focus lens of the cutting head of the laser cutting machine and check whether it is damaged.
5. Pay attention to the surrounding environment and personal safety when using air, especially when using oxygen to assist cutting.

1. The laser and laser cutting machine should keep the appearance clean and tidy, and clean it frequently.
2. Clean up the debris on the filter screen of the exhaust outlet in time to ensure that the ventilation pipe is unblocked.
3. Monitor and check whether the switch of the laser mechanical shutter is normal.
4. The laser cutting nozzle should be cleaned every 30 minutes or so to remove the metal slag sprayed on it.
5. Before work, every day, check whether the x, y, and z axes of the laser cutting machine can return to the original point. If there is any problem, check whether the position of the origin switch striker is offset.
6. Use an air gun to clean the dust on the heat exchange fins of the water cooler and freeze dryer, and blow the dust to ensure the heat dissipation efficiency.
7. Check the cooling water temperature, the laser water inlet 19℃≤temperature≤22℃. The temperature change is around 21°C. The inlet pressure is between 4 and 5 bar.
8. Check the freeze dryer, press the start button to see if the indicator light is on. Does the automatic drain water regularly? In the state of stopping and without compressed air, whether the pointer of the evaporation thermometer is lower than the ambient temperature, about 5-15℃ lower than the ambient temperature is normal. In the state of operation and compressed airflow, whether the pointer of the evaporation thermometer is in the green area.
9. Check the working status of the voltage stabilizer frequently: observe whether the temperature rise of the compensation transformer and the voltage regulating transformer is normal, whether there is overheating, discoloration of the coil, etc.; whether the carbon brush contact is good; monitor whether the input and output voltages are normal; whether there is an overload phenomenon Wait. Once abnormalities are found, they should be dealt with immediately. If it cannot be handled, please contact the manufacturer to solve it in time to avoid damage to the equipment.

Please contact customer service for a complete set of laser cutting machine maintenance manuals.
